Vision 3200W Electric Radiant Heater
Subtle orange glow which is
only 30-40% of the light output
HEATSCOPE® Vision 3200W ambient heater emits medium-wave infrared light with its parallel carbon heating strands. Since the already low luminosity of less than 300 lux is still dimmed by the glass-ceramic front, a cozy atmosphere is created.
Configure & Buy
Buy online and get it delivered to your door.
Customer Inspiration #heatscopeheaters
Key Features
Efficiency made simple
HEATSCOPE® is committed to efficiency! All VISION, SPOT and PURE radiant heaters were developed in accordance with the newest findings concerning the mid-wave IR range. This means that between 90% and 94% of the energy used is turned directly into ambient heat.
Real infrared
All HEATSCOPE® design radiant heaters produce natural infrared heat in the (fast) mid-wave IR range. This means that the heat feels particularly pleasant and is effective exactly where it is needed – that’s directly under the first layers of skin, but not too deep in the tissue.
Inviting & cosy
Other radiant heaters use light tubes to produce heat as a by-product – at HEATSCOPE® we exclusively use innovative carbon technology: two carbon spirals are powered with an electric current, they begin to glow and produce a particularly pleasant warmth.
Super fast
Output peaks are a thing of the past with HEATSCOPE® power heaters. Although the heaters start up slowly, they reach 100% in no time: the range of SPOT models take only 15 seconds, and the VISION & PURE range takes a maximum of 30 seconds owing to the glass front.
Full control
The separate model ranges are either delivered with their own IR remote control or with a 4-wire cable for integration into an external control system (output dependent).
Award-winning design
Delivers pleasant heat without the distraction. Clean-cut, modern designs and colours easily blend into any decor.
Weather-resistant
All models are certified with an IP rating for protection against dust, splash-water, and wind.
No aggressive red light
Produces a very ambient, modest light based on double carbon heating elements.
High efficiency
Up to 94% of the energy used is turned into ambient heat and transferred directly to nearby people and surfaces for maximum efficiency.
Smart switch
Operate and sync your heater(s) with your smart device (compatible with Alexa and Google Assistant). *Internet connection and additional accessories required
2-year warranty
Our radiant heaters come with an industry leading two-year limited warranty.
Technical Specifications
Installation Height
Power / Current
Voltage
Max. Power In
Radiant Efficiency
Visible Light
Coverage Area
This graphic shows the heating performance of Heatscope Vision 3200W heaters. Please note that the heat output always depends on a wide range of factors.
They include: Installation environment (indoors or outdoors, enclosed or open, wind-protected or wind-prone), installation height, radiation angles, weather, voltage fluctuations, etc.
Please consider all these factors in your planning.
*All values are approximate. Max. temperature increases achievable in enclosed spaces at 16 °C (dependent on the respective installation conditions and mounting height).
Construction
- MPN (Black) MHS-VE3200AB.100
- MPN (White) MHS-VE3200WT.100
- Weight 10kg [22.05lb]
- Model Dimensions mm [in] L 1660mm [65.4in] W 184mm [7.2in] H 87mm [3.4in]
- Application Indoor & Outdoor
- Materials Aluminum body, glass ceramic front
- Colours
Accessories
Includes everything you need to easily operate and protect your investment for many years to come.
Product Reviews
FAQ's
View AllCan HEATSCOPE® heaters be mounted directly on a wooden structure?
HEATSCOPE® infrared heaters are supplied with optional mounting devices such as spacers to meet the recommended minimum clearances from combustible material. When used, it is safe to mount the appliance to the wood supporting structure.
What can I expect from my HEATSCOPE® radiant heater?
HEATSCOPE® Radiant Heaters provide a beautiful system and comfortable heat. With award-winning modern designs our heaters easily blend into any decor. You’ll enjoy convenient fast heating and pleasant warmth to extend your time outdoors in all seasons. HEATSCOPE® Radiant Heaters are weather-resistant and IP certified for protection against dust, splash-water, and wind.
What are the main advantages of HEATSCOPE® radiant heaters compared to gas-powered heating appliances?
HEATSCOPE® heaters are easier to install and do not require a gas connection. This provides you with more design flexibility and less hassle. HEATSCOPE® radiant heaters are eco-friendly and don't produce harmful emissions. Additionally, electric infrared heaters are low-maintenance and will not have issues with ignition, gas pressure, or hoses which can kink or crush over time.
Is there any heat loss with electric radiant heaters?
HEATSCOPE® radiant heaters are highly efficient, very economical to run, heat quickly, and warm a wider area than conventional electric and gas patio heaters.
Does my HEATSCOPE® radiant heater need to be on a Safety Switch (RCD)?
Yes, this is in accordance with AS/NZS 3000:2018 wiring rules.
Are there any guidelines that I must follow to install the radiant heater?
Your electrician must follow the installation instructions set by the manufacturer, and make all connections in accordance with AS/NZS 3000:2018 Wiring rules. Please refer to the installation manual.
Can I control HEATSCOPE® infrared heaters continuously with a standard dimmer?
HEATSCOPE® infrared heaters cannot be controlled with a standard dimmer due to the amount of power required.
HEATSCOPE® VISION and Spot heaters can be controlled with an on/off switch or via an infrared remote control with two switchable power levels, (on/off, 100%, 50%).
Are HEATSCOPE® heaters water resistant?
All HEATSCOPE® VISION and SPOT radiant heaters are protected against dust and splash-water (IP44 and IP24)! In other words: the heaters require additional protection from above/behind against persistent or strong rain, such as a canopy or roof.
In general though a wall projection (or similar) is sufficient. If no rear protection is possible and the heater is to hang completely freely, a HEATSCOPE® weather protection shield is obligatory in all cases.
The weather protection shields are available in black or white and incorporate the shape and curvature of the rear side of the design radiant heater.
In this way, HEATSCOPE® VISION (IP44) and SPOT (IP24) heaters are optimally protected against wind and weather.
